FixturLaser EVO Shaft Alignment System

An All Digital Tool
Fixturlaser was the first to use the digital CCD technology in sensors of this kind
and, hence, the first to deliver a digital shaft alignment system to the market.
With a 30 mm CCD detector, you are able to obtain unparalleled repeatability
together with outstanding precision alignment, regardless of ambient light and
measurement environment. The benefit over the older analog PSD technology is
unmatched with regards to the capability of filtering and refining the measurement
data.
Another benefit is the size of the sensors that are very compact, only 33 mm thick,
and therefore easy to fit into even the tightest spaces.

Simplicity in Your Hands
– EVO, is all about evolved simplicity.
It is a product without the frills and the bling bling. It stays true to our core values: simplicity, user friendliness and innovative techniques. The EVO offers a compact display unit with a 5” color touch screen. It is slim and balanced, allowing you to hold it in one
hand, leaving your other hand free to touch the screen icons and rotate the shafts.
It has a clean and color coded graphic user interface that helps the maintenance professional throughout the measurement and
alignment process without any hassles and stress.
The EVO comes with an extensive shaft alignment package, including the Feetlock function that is useful in base/bolt-bound
machine situations.

VertiZontal
– Acoem has developed an adaptive user interface, i.e. a user interface that actually tells
you what to do based on your measurement results. With the VertiZontal Moves feature, we have
brought to you one of the most innovative and time saving features in the shaft alignment world.
The adaptive user interface shows how much a misaligned machine requires to be adjusted by
adding or removing shims at the machine’s feet. When proceeding with the measurement, you
no longer need to remeasure in between the vertical and the horizontal adjustment during the
adjustment process. The following horizontal adjustment is promptly carried out with real values
displayed.
