Fixturlaser NXA Pro Laser Shaft Alignment System

Original price was: $9,400.00.Current price is: $4,700.00.

The NXA Pro has a power management system that will make your life so much easier! The display unit has a 10 hour continuous battery operating time, and should the need arise during an alignment job; the display unit can be express charged to an 80% capacity in one hour. The sensor units will last for 24 hours minimum thanks to the long-life batteries.

Category: NDT Inspection Tag: FixturLaser Brand: FixturLaser

Description

Fixturlaser NXA Pro Laser Shaft Alignment System

Acoem NXA Pro is the most user-friendly and cost-effective laser alignment system in the industry.

The Acoem NXA Pro not only revolutionizes shaft alignment but also elevates the user experience with our advanced GuideU™ interface. This intuitive system ensures lightning-fast and straightforward operations while granting access to exceptional features. Moreover, it boasts one of the most robust power management systems on the market.

But that’s not all. When you choose the Acoem NXA Pro, you also enjoy the peace of mind that comes with a lifetime warranty and a comprehensive system. Experience the future of shaft alignment, elevated by GuideU™ and backed by our commitment to quality.

OmniView™

The graphical user interface is shown off on a 6,5” transreflective display screen with icons and symbols to guide you, in other words, no text is involved.

The adaptive user interface will guide you throughout the measurement and alignment process.

We have fitted the NXA Pro with gyros and can, therefore, adapt the screen view from the same side that the user is positioned – our OmniView™ function, i.e. the system knows where it is in relation to the machine.

TD Units

Weight: 192 g.
Dimensions: 92 x 77 x 33 mm
Environmental protection: IP 65 (Dust tight and protected against water jets)
Measurement distance: Up to 10 m
Detector: 2-nd generation Ultra HD CCD
Detector length: 30 mm
Detector resolution: 1 μm
Measurement accuracy: 0,3% ± 7 μm
Gyroscope: 6-Axis MEMS Inertial Motion Sensor with drift compens tion and automatic field calibration
Operating time: 17 hours continuous use (measuring)
