JEISYS Tri-Beam Premium Tattoo Removal Laser System

Original price was: $13,880.00.Current price is: $7,120.00.

JEISYS Tri-Beam Premium Tattoo Removal Laser System
with zoom collimated handpiece. Excellent application on laser toning treatment. Very Fast Treatment Times. 2mm. 10mm （Rich-PTP technology）, an proprietary technology that reduces irritation (inflammatory reaction)

Category: Beauty Laser Equipment Tag: JEISYS

Description

JEISYS Tri-Beam Premium Tattoo Removal Laser System

JEISYS Tri-Beam Premium Tattoo Removal Laser System with zoom collimated handpiece. Excellent application on laser toning treatment. Very Fast Treatment Times. 2mm. 10mm （Rich-PTP technology）, an proprietary technology that reduces irritation (inflammatory reaction)

Two Type Handpieces as standard equipment

TRIBEAM Premium is equipped with two handpieces: Collimation handpiece with fixed 7mm spot regardless of hand distance and Zoom handpiece with variable 2-10mm spot at hand in 1mm increments
Zoom Collimation Two handpieces as standard equipment Zoom/Collimation Zoom–spot
size 2-10mm Collimation–spot size 7mm

The larger the spot size, the deeper the penetration depth of the laser, and the more heat is transmitted to deeper layers. Therefore, the larger the area irradiated at one time, the deeper the penetration depth at the same time.
Zoom handpiece, with its 2mm to 10mm irradiation range, can efficiently treat deep pigmented diseases such as Ota’s nevus and ADM, as well as tattoo and tattoo removal.Collimation handpiece has a large spot size of 7mm, which not only has a wide irradiation range, but also can reach deep into the skin.

Technical Specifications

Dimensions: H 790mm x W 310mm x L 690mm (without articulated arm)
Weight: 110kg
Electrical power: 220V, Single Phase, 50/60Hz, 20 Amps @ 220V AC
Laser medium: Nd:YAG Q-Switched
Operating parameters: Q-Switched & Quasi-Long Pulse
Wavelength: 1064/532nm
Handpiece energy: Q-Switched Top Hat mode – 1064nm 1.6 Joule/double pulse / Gaussian mode – 1064nm 1.5 Joule/pulse / 532nm 500mJoule/pulse Quasi-Long Pulse 1064nm 3.5 Joule
Cooling: Closed cycle water to air heat exchanger

Maximum pulse energy density: Q-Switched Top Hat mode – 1064nm 22.6J/cm² @ 3.0mm spot size 532 nm 7.0J/cm² @ 3.0mm spot size Quasi-Long Pulse: 1064nm 12.3J/cm² @ 6.0mm spot size
Pulse width: Q-Switched – 5-10ns / Quasi-Long Pulse – 300us
Repitition rate: single shot, 1-20Hz pulses per second
Beam profile: True Flat-Top Hat
Energy calibration: External
Spot sizes: Zoom handpiece – 1064nm 2mm ~ 10mm / 532nm 2mm ~ 10mm Collimator handpiece – 6mm Fractional handpiece (optional) 5mm x 5mm (81 spots)
Beam delivery: Articulated arm with up to 240cm reach, 7-joint 360° rotation
