Name: Olympus OmniScan X3 64-Channel Flaw Detector
Brand: Olympus
SKU: 757
Availability: InStock

Sale!

Previous Product

Olympus OmniScan X3 64-Channel Flaw Detector

Original price was: $17,700.00.Current price is: $10,920.00.

With the release of MXU 5.11 onboard software for OmniScan™ X3 and X3 64 flaw detectors, the file format of data files created with these devices has changed from .odat to .nde. This change is the beginning of a shift in how NDT data is managed and accessed. It starts with the OmniScan X3 series but will be applied to all future Evident nondestructive testing software and hardware platforms, and hopefully it will be extended to and used by the entire NDT industry.

Category: NDT Inspection Tag: Olympus Brand: Olympus

Description
Reviews (0)

Description

Olympus OmniScan X3 64-Channel Flaw Detector

Save Time and Energy Screening Welds with the Merged B-Scan

If you’ve ever wondered whether there’s a more efficient way to perform weld screening than simply scrolling through B-scans, you’ll want to hear about our solution. With the MXU 5.13 software update, we introduced an innovative B-scan view for the OmniScan™ X3 series that has the potential to revolutionize this time- and attention-consuming technique. Used as a validation tool, it can give you more confidence in your assessments and help ease the whole B-scan screening process.

5 Main Advantages of Phase Coherence Imaging (PCI)

With the release of MXU 5.10 software, the OmniScan™ X3 64 flaw detector gains a new advanced ultrasonic inspection technique: phase coherence imaging (PCI). As soon as your OmniScan X3 64 unit is updated, you can start taking advantage of PCI to achieve live total focusing method (TFM) images with unprecedented clarity and sensitivity to small defects.

Package includes:

– OmniScan X3 64 flaw detector 64:128PR
– OmniScan MXU software
– 10L16-9.6X10-A10-P-2.5-OM: Standard Phased Array Probe, 10 MHz Linear Array, 16 Elements
– SA10-IHC: Standard removable IHC option for SA10 wedges
– SA10-N55S: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD3.5: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD4.5: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD6.625: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD8.625: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD10.750: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD12.750: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD24: Custom Wedge for Angle Beam Phased-Array Probe A10
– 5L32-32X10-A32-P-5-OM: Standard Phased Array Probe, 5.0 MHz Linear Array, 32 Elements
– SA32-N55S-IHC: Standard Wedge for Angle Beam Phased-Array Probe Type A31
– ENC1-5-LM: Mini encoder, 5 m cable, waterproof with Lemo connector
– WTR-SPRAYER-8L: Portable manual couplant feed unit
– TB7567-1: NAVSHIPS Block. 1018 Steel
– 93 Wh lithium-ion battery
– Spare screen protector
– DC charger with power cord
– USB key with MXU Software and User’s Manuals
– Empty USB key for file transfer purposes
– Complimentary OmniPC analysis software
– Calibration certificate
– Transport case
