Name: SciAps X-505 Handheld XRF Analyzer
Brand: SciAps
SKU: 746
Availability: InStock

Sale!

SciAps X-505 Handheld XRF Analyzer

Original price was: $13,250.00.Current price is: $6,525.00.

A major advancement for aluminum alloy sorting. The historic weakness of X-ray has been aluminum alloy sorting. This is because most X-ray guns are poor at measuring magnesium (Mg), and Mg analysis is critical to correctly sorting aluminum alloys. The X-505 was designed for optimal sensitivity to Mg, and therefore silicon (Si). The result is an analyzer that offers accurate sorting of the many complex grades of aluminum alloys. See our Guide to Aluminum Alloy Sorting
Great on high temp alloys and precious metals.
Like most XRFs, the -505 provides fast, precise chemistry on the wide array of high temperature alloys, stainless, red metals and precious metals

Category: NDT Inspection Tag: SciAps Brand: SciAps

Description

SciAps X-505 Handheld XRF Analyzer

The SciAps X-505 is the smallest, lightest weight handheld X-ray analyzer ever made. In terms of speed, it is second only to the X-550. Weighing in at 2.8 lbs. with the battery, it delivers the small size, blazing speed and high precision of the SciAps X Series in a perfectly balanced device. It’s fast on all alloys, including aluminums. With its state-of-the-art design and excellent heat handling, the X-505 can run all day long, even in the hottest climates, without requiring down time due to overheating.

Applications

NDT-PMI
Residuals in the Alloy App
Sulfidic Corrosion in the Alloy App
Scrap Processing
Great on high temp alloys and precious metals.
Tramps Elements
Mining
Soil
RoHS Applications
General Analytical

Specs :

Weight
3.3 lbs with battery

Excitation Source
6-40kV, 200uA Rh anode for alloy testing, 6-50kV, 200uA Au anode for most other apps.

Calibration
Fundamental parameters. For Geochem and Env. Soil Apps, users may also choose “Compton Normalization” method and/ or use empirically derived calibrations.

Dimensions
7.25″ x 10.5″ x 4.5″

Detector
20mm2 silicon drift detector (active area), 135eV resolution FWHM at 5.95Mn K-alpha line.

Calibration Check
Internal shutter is also 316 stainless for totally automated calibration and energy scale validation.

Power
On board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power, hot-swap capability (60s max swap time).

X-Ray Filtering
6 position filter wheel for beam optimization.

Environmental Temp. Range
10°F to 130°F at 25% duty cycle

Display
5″ color touchscreen Smartphone type display – PowerVR SGX540 3D graphic.

Processing Electronics Host Processor
ARM Cortex -A9 dual-core / 1.2GHz Memory: 1GB DDR2 RAM, 1GB NAND Results Storage: 8GB SD

Security
Password protected usage (user level) and internal settings (admin).

Comms/ Data Transfer
Wifi, Bluetooth, USB. Connectivity to most devices, including SciAps Profile Builder PC software.

Pulse Processor
14-bit ADC with digitization rate of 80 MSPS 8K channel MCA USB 2.0 for high speed data transfer to host processor Digital Filtering implemented in FPGA for high throughput pulse processing 50nS – 24uS peaking time

Regulatory
CE, RoHS, USFDA registered, Canada RED Act.CE, RoHS, USFDA registered, Canada RED Act.

INCLUDED :

PC Software for PC operation
import/export of results
data management
2 Li-Ion batteries
battery charger
ruggedized carrying case
spare Prolene windows
